Sany 71M Concrete Pump Truck for Heavy-duty Construction Gross weight 55000kg

Sany 71M Concrete Pump Truck for Heavy-duty Construction Gross weight 55000kg

Brand Name: Sany
Model Number: SYM5442THBE 710S
MOQ: 1
Price: USD 300000 - USD 500000 per unit
Payment Terms: T/T,Western Union,MoneyGram,D/A,L/C,D/P
Supply Ability: 1000
Detail Information
Place of Origin:
China
Type:
Concrete Pump Truck
Condition:
New
Boom Length:
71 Meters
Brand:
Sany
Gross Weight:
55000kg
Packaging Details:
N/M
Supply Ability:
1000
Highlight:

71M Concrete Pump Truck

,

55000kg Concrete Pump Truck

,

Heavy duty Concrete Pump Truck

Product Description

SANY SYM5552THB 710S 71m Concrete Pump Truck – New, Ready for Inspection

The SANY SYM5552THB 710S is a state-of-the-art 71-meter concrete pump truck, engineered for high-efficiency concrete placement in large-scale construction projects. Built on a self-developed SANY chassis, this model combines robust performance, advanced pumping technology, and superior maneuverability.

Key Specifications:

  • Boom System:

    • Boom Length: 71 meters (5-section, Z-type folding)

    • Maximum Vertical Reach: 65.5m | Horizontal Reach: 50.2m

    • Pumping Pressure: 13.5 MPa | Theoretical Output: 170 m³/h

    • Slewing Angle: ±270° (full rotation)

  • Pumping System:

    • Cylinder Diameter × Stroke: Φ260 × 2100mm

    • Delivery Pipe Diameter: Φ125mm (standard)

    • Max Aggregate Size: 40mm (recommended: ≤30mm for optimal flow)

    • Concrete Slump Range: 120–230mm

  • Chassis & Powertrain:

    • Chassis Model: SANY SYM5552THB (self-manufactured)

    • Engine: Euro III-compliant diesel, 420 HP

    • Transmission: 10-speed manual

    • Axle Configuration: 10×6 (10-wheel drive, 6 axles)

    • Max Traveling Speed: 80 km/h

  • Advanced Features:

    • Intelligent Control: SANY EPC (Electronic Pump Control) system for precise operation.

    • Anti-Sway Technology: Enhances stability during boom extension.

    • Emergency Safety: Automatic pressure relief and overload protection.

    • Fuel Efficiency: Optimized hydraulic system reduces energy consumption.

  • Dimensions & Weight:

    • Overall Length × Width × Height: 15.2m × 2.55m × 3.98m

    • Gross Vehicle Weight (GVW): 55,000 kg

This brand-new SANY 71m pump truck is immediately available for inspection and delivery, offering unmatched reliability for high-rise buildings, bridges, and industrial projects.

Contact us today to arrange a viewing!



Pump Brand Sany
Boom Length 71 Meters
Chassis Sany
Manufactured Year N
Condition New
Model SYM5552THB 710S
