Best Brand 50 ton Hydraulic Telescopic Truck Crane STC500C5-8 Mobile Crane

Name: Best Brand 50 ton Hydraulic Telescopic Truck Crane STC500C5-8 Mobile Crane
Brand: Hunan Teila Heavy Industry Machinery Group Co., Ltd
SKU: STC500C5-8
Price: 95,000.00 USD
Availability: InStock

Brand Name:	SANY
Model Number:	STC500C5-8
MOQ:	1
Price:	$80000-110000
Payment Terms:	T/T
Supply Ability:	500 pieces/Year

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Model:

STC500C5

Counterweight:

8.5 T

Wheel Formula:

8x4x4

Boom Shape:

U Shape

Packaging Details:

Bulk Cargo Shipping

Supply Ability:

500 pieces/Year

Highlight:

stc500c5-8 used truck crane

stc500c5-8 used truck mobile crane

50 ton used truck crane

Product Description

1. Smart Hydraulics
· Larger flow ensures higher efficiency, enabling higher speed of wire rope reeling. Shunted mode of independently controlled combined motions realizes higher stability under simultaneous vibration-free luffing and hoisting movements.

2. Double Pump Intelligent Flow Distribution System
· The electro-hydraulic control system realizes effective flow distribution, featuring quick response to combined motions and small impact shock, energy saving, and environmentally friendly.

·Precise control: Excellent inching performance, min. The stable speed of a single rope is 1.2m/min and min. The sound speed of slewing is 0.1°/s, realizing precise lifting of mm level.

·Integrated slewing buffer control: boost buffer, sequential brake, and free swing technology-smooth start and stop.

3. High-performance Chassis
· Innovative structural frame verified by 200,000 cycling fatigue tests to ensure high reliability.

4. Smart Control System
· CAN BUS system: Controllers, displays, meters, I/O modules, sensors, etc., are integrated into CAN Bus networking and fast-responsive.

· Fault diagnosis system: Operating device with intelligent controller, body with BCM module, accurately locating the fault point, making the maintenance convenient.

· The load moment indicator system protects against overloading, release, and over-winding.

5. Electrical Control
· Simple harness and steady signal transmission ensures real-time auto monitoring of operation conditions.

Model	STC500C5
Counterweight	T	8.5
Max. Lifting Capacity	T	50
Max. Boom Length	m	44
Max. Lifting Height	m	60.5
Max. Lifting Moment	kN·m	1600
Engine model		ISLe340 40 (Euro III)
Max. engine power	kW/rpm	250/2100
Max. engine torque	N·m/rpm	1450/(1100~1400)
Overall length	mm	13660
Overall width	mm	2650
Overall height	mm	3700
Max. travel speed	km/h	90
Min. steering radius	m	12
Min.steering radius of boom tip	m	14.6
Wheel formula		8x4x4
Min. ground clearance	mm	260
Approach angle	°	19
Departure angle	°	13
Max. gradeability		45%
Fuel consumption per 100km	L	37
Working temperature range	ºC	-20~+45
Min.rated lifting radius	m	2.5
Tail slewing radius	m	3.84
Boom sections (Qty.)		5
Boom shape		U shape

Best Brand 50 ton Hydraulic Telescopic Truck Crane STC500C5-8 Mobile Crane 0

Best Brand 50 ton Hydraulic Telescopic Truck Crane STC500C5-8 Mobile Crane 1

Best Brand 50 ton Hydraulic Telescopic Truck Crane STC500C5-8 Mobile Crane 2

1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .

2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 13 years.

3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.

4:How do I know the condition of the original used or re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.

5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
