Teila 28M Concrete Pump Mixer Truck HMG5432JBC-28 Truck Mixer Concrete Pumps

Name: Teila 28M Concrete Pump Mixer Truck HMG5432JBC-28 Truck Mixer Concrete Pumps
Brand: Hunan Teila Heavy Industry Machinery Group Co., Ltd
SKU: HMG5432JBC-28
Price: 175,000.00 USD
Availability: InStock

Brand Name:	Teila
Model Number:	HMG5432JBC-28
MOQ:	1
Price:	$160000-$190000
Payment Terms:	T/T
Supply Ability:	5

Detail Information

Product Description

Detail Information

Place of Origin:

Changsha

Supply Ability:

Highlight:

Teila 28M Concrete Pump Mixer Truck

HMG5432JBC-28 Truck Mixer Concrete Pumps

Product Description

Mixer truck, pump truck integrated, efficient, stable and profitable mchinery .

(Name)	(Content)	(Technical parameters)
(Vehicle Parameters)	(Full Length)	10890mm
	(Total Width)	2520mm
	(Total Height)	4000mm
	(Gross Weight)	42300kg
	Effective volume of mixing drum(m³)	9.2
(Boom Leg Parameters)	(Vertical Reach)	28M
	(Horizontal Reach)	24M
	(Depth Reach)	17M
	(Minimum Unfolded Height)	6.6m
	(Turntable Rotation Angle)	±270 º
	(Front Outrigger Spread Width)	5340mm
	(Rear Outrigger Spread Width)	2660mm
(Pumping System Parameters)	(Theoretical Output)	65m³/h
	(Theoretical Pressure-High Pressure)	8MPa
	(Theoretical Pumping Times)	31time/minute
	(Conveying Cylinder Inner Diameter)	200mm
	(Conveying Cylinder Stroke)	1000mm
	(Hydraulic System)	Open
	(System Oil Pressure)	32MPa
	(Fuel Tank Volume)	400L
	(Water Tank Volume)	650L
	(Conveying Pipe Diameter)	125mm
	(End Hose Length)	3m
(Chassis Parameters)	(Chassis Brand )	SITRAK
	(Chassis Model)	ZZ1316N306GF1
	(Engine Model)	MC07H35-60
	(Engine Power)	257KW (350HP)
	(Axis distance)	2000+2850+1350
	(Fuel Tank Volume)	400L
	(Gearbox Model)	HW15710L
	(Speed Ratio)	5.32
	(Drive form)	8*4

Teila 28M Concrete Pump Mixer Truck HMG5432JBC-28 Truck Mixer Concrete Pumps 0

Teila 28M Concrete Pump Mixer Truck HMG5432JBC-28 Truck Mixer Concrete Pumps 1

Teila 28M Concrete Pump Mixer Truck HMG5432JBC-28 Truck Mixer Concrete Pumps 2

Teila 28M Concrete Pump Mixer Truck HMG5432JBC-28 Truck Mixer Concrete Pumps 3

Teila 28M Concrete Pump Mixer Truck HMG5432JBC-28 Truck Mixer Concrete Pumps 4

Teila 28M Concrete Pump Mixer Truck HMG5432JBC-28 Truck Mixer Concrete Pumps 5

Teila 28M Concrete Pump Mixer Truck HMG5432JBC-28 Truck Mixer Concrete Pumps 6

1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .

2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 13 years.

3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.

4:How do I know the condition of the original used or re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.

5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
