Used 2024 Sany 71m pump truck with Sany chasis for hot sale

2024 Sany 71m pump truck with Sany chassis

1.Description:

The vehicle parameters of the Sany 71-meter pump truck include a total length of 16090mm, a total width of 2550mm, a total height of 4000mm, and a total weight of 55000kg. In terms of pumping system parameters, the theoretical concrete displacement is 180m³/h at low pressure and 125m³/h at high pressure, the theoretical pumping pressure is 8.3Mpa at low pressure and 13Mpa at high pressure, the theoretical pumping times are 29 times/minute at low pressure and 19 times/minute at high pressure. The hydraulic system adopts an open system, the oil pressure is 32Mpa, the oil tank capacity is 960L, the water tank capacity is 750+750L, and the delivery pipe diameter is 125mm‌

2. Applications

‌High-rise construction: Sany 71m pump truck is suitable for high-rise construction. Its long boom design allows for a wider distribution range and can easily meet the concrete delivery needs of high-rise buildings.

‌Narrow construction sites‌: The pump truck adopts an integrated upper and lower installation design, with a more reasonable center of gravity distribution and a shorter body, which is suitable for working on narrow construction sites and has better site adaptability‌

Complex terrain: Due to its strong adaptability and flexible material distribution capabilities, the Sany 71m pump truck is also suitable for construction in complex terrain and irregular sites.

3.Specifications:

4.Feature Advantages

High-efficiency pumping system: Sany's 71-meter pump truck uses a newly upgraded S-class pumping system. The streamlined large hopper has a 10% higher volume, does not suck air during pumping, and has a suction efficiency of over 90%. The exclusive patented three-blade mixing system has a 50% higher efficiency, the platform pipe diameter is increased, the pipeline pressure loss is reduced by 15%, the pumping speed is increased by 10%, and one more truck of material can be pumped per hour.

Intelligent control: Equipped with a 318 cab and a 15.6-inch large touch screen, the vehicle operation status can be visually monitored, and vehicle information can be mastered on one screen. It has functions such as one-button start, cruise control, voice wake-up, and rapid fault diagnosis, making operation more convenient and safer.

‌Economy‌: Equipped with a new Deutz engine and upgraded fuel system, the economic fuel consumption range is expanded to 1000-1700 rpm. Based on an annual construction of 80,000 cubic meters, it can save 60,000 yuan in fuel costs compared to pump trucks in the same industry. In addition, the pump truck adopts a soft mode, one-button shifting, a lower speed, a larger displacement, improved efficiency and more fuel-saving‌

Safety and reliability: As the only fully regulated pump truck with five axles and the maximum bridge length ratio on the market, the Sany 71-meter pump truck relies on the industry chain specially built for pump trucks by Sany, and its core components are self-developed and manufactured to ensure high quality and reliability of the equipment. The chassis adopts an integrated special chassis designed for pumping conditions, which has been tested on 20,000 kilometers of reinforced road surface, and its performance is reliable and durable.

Strong adaptability: The upper and lower parts are integrated, the center of gravity is more reasonably distributed, the body is shorter, and it can pass through narrow construction sites. The 6RZR folding boom has good stability, 360° full flatness and flexible construction, and no dead angle for laying materials. The boom is extended by 3 meters based on the previous generation 68-meter pump truck, just enough to build an extra floor.

5.Company Profile:

FAQ:

1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .

2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 13 years.

3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.

4:How do I know the condition of the original used or re-manufacturing  concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.

5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
