MOQ: | 1 |
Price: | $50000-$70000 |
Payment Terms: | T/T |
Supply Ability: | 500pieces/Year |
Excellent and stable chassis performance /chassis system
* Double-axle drive is used, providing good trafficability and comfortableness under complex road conditions with reliable traveling performance, and the rear axle is equipped with rubber suspension and V-shaped thrust lever which provide less vibration and a comfortable traveling feeling.
* The engine has the multimode power output function, which reduces power consumption. The use of tipping over early-warning technology provides high stability and safety of the overall operation.
Ultra-long, super strong and highly sensitive load lifting capacity
* Five-section boom of high strength steel structure and optimized U-shaped cross-section reduces weight significantly with higher safety rates. Jib mounting angles are 0°, 15°, and 30° which ensures fast and convenient change-over between different operating conditions so as to improving the working efficiency of the machine.
Highly efficient, stable, energy-saving, and adjustable electrical proportion hydraulic system
* Load feedback of hydraulic system, constant power control, piston pump and the electrical control valve is applied to provide strong lifting capacity and good micro-mobility. A unique steering buffer design is adopted to ensure stable braking operation.
Safe, stable, advanced, and intelligent electric control system
* The adoption of full-digital network control technology ensures stable control signal, simple harness, and high reliability. Timely feedback of data information can achieve the monitoring of the overall working status in realtime; the load moment limiter equipped with the comprehensive intelligent protection system is used with accuracy within 3% to provide a comprehensive logic and interlock control, thus ensuring more safe and reliable operation.
Capacity
|
Max. lifting capacity
|
25ton
|
Dimensions
|
Overall length
|
12750mm
|
Overall width
|
2500mm
|
|
Overall height
|
3550mm
|
|
Axles
|
3
|
|
Axle distance-1,2
|
4325mm
|
|
Axle distance-2,3
|
1350mm
|
|
Weight
|
Overall weight
|
30000kg
|
Front axle load
|
6500kg
|
|
Rear axle load
|
23500kg
|
|
Rated power
|
213kw/2100r/min
|
|
Rated torque
|
1050N·m/1200~1400r/min
|
|
Emission standard
|
Euro 3
|
|
Traveling
|
Max. traveling speed
|
80km/h
|
Min.turning radius
|
10m
|
|
Min.turning radius of boom head
|
12 m
|
|
Drive train
|
6×4
|
|
Min. ground clearance
|
220mm
|
|
Approach angle
|
17 °
|
|
Departure angle
|
12 °
|
|
Max. gradeability
|
38%
|
|
Fuel consumption per 100km
|
≤ 37L
|
|
Min.lifting radius
|
3m
|
|
Tail swing radius of superstructure
|
3.37m
|
|
Boom section
|
4
|
|
Boom shape
|
U-shaped
|
|
Max. lifting moment-Base boom
|
962kN·m
|
|
Max. lifting moment-Full-extend boom
|
544kN·m
|
|
Max. lifting moment-Full-extend boom+jib
|
341kN·m
|
|
Length-Base boom
|
10.65m
|
|
Length-Full-extend boom
|
33.5m
|
|
Length-Full-extend boom+jib
|
41.5m
|
|
Outrigger span(Longitudinal/Transversal)
|
5.3m × 6.2m
|
|
Jib offset
|
0 ° 15 ° 30 °
|
|
Working Speed
|
Max. single rope lifting speed of main winch(no load)
|
120m/min
|
Max. single rope lifting speed of auxiliary winch(no load)
|
120m/min
|
|
Full extend/retract time of boom
|
70 / 50s
|
|
Full raise/lower time of boom
|
70 / 55s
|
|
Swing speed
|
0~2 r/min
|
|
Aircondition
|
HVAC in up cab
|
Cooling and Heating
|
HVAC in low cab
|
Cooling and Heating
|
1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .
2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 13 years.
3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.
4:How do I know the condition of the original used or re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.
5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
