Brand Name: | ZOOMLION |
MOQ: | 1 |
Price: | USD70000-USD150000 EXW |
Payment Terms: | L/C,T/T |
Specification |
Details |
Maximum Theoretical Delivery Volume |
180m³/h |
Maximum Concrete Outlet Pressure |
11.3MPa |
Rated Working Pressure |
42MPa |
Pumping Frequency |
26min-1 |
Concrete Cylinder Diameter x Stroke |
Φ260x2100mm |
Structure Form |
63X-7RZ |
Maximum Placement (Height) |
62.1m |
Maximum Placement (Radius) |
56.9m |
Maximum Placement (Depth) |
46.4m |
Slewing Angle |
±270° |
Outrigger Span (Front) |
12250mm |
Outrigger Span (Rear) |
12820mm |
Outrigger Span (Longitudinal) |
11660mm |
Chassis and Vehicle Emissions |
China V /Euro ⅤEmissions Standards |
Benz Chassis for Superior Performance:
Efficient Pumping Technology:
Enhanced Stability and Safety:
Vibration Reduction and Energy Efficiency:
Smart Monitoring System:
High-rise Building Construction:
Infrastructure Development: bridges, tunnels, and highways, where large volumes of concrete need to be placed accurately and efficiently.
Large-scale Commercial and Residential Projects:
Energy and Utilities: power plants and water treatment facilities, where precision and efficiency in concrete placement are crucial.
1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .
2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 13 years.
3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.
4:How do I know the condition of the original used or re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.
5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
